| Bimetal Alloys Display | |||||||
| SB Material Code | SB-792 | SB-799 | SB-820 | SB-830 | SB-840 | SB-783 | |
| SAE Code / DIN Code | SAE-792 | SAE-799 | DIN17670 | BS PB1 | CuSn6 (2.1020) | SAE783 | |
| ISO Code | CuPb10Sn10 | CuPb24Sn4 | CuPb6Sn6Zn3 | CuSn10 | CuSn6.5P | AlSn20Cu | |
| Backing Material | Low Carbon Steel ST-12 / SAE1010 | ||||||
| Chemicals (%) | Cu | Balance | Balance | Balance | Balance | Balance | 0.7~1.3 |
| Pb | 9.0~11.0 | 21.0~27.0 | 2.0~4.0 | 0.1 | 0.1 | - | |
| Sn | 9.0~11.0 | 3.0~4.5 | 5.0~7.0 | 9.0~10.0 | 6.0~6.8 | 17.5~22.5 | |
| Zn | 0.5 | 0.5 | 5.0~7.0 | 0.3 | 0.3 | - | |
| P | 0.1 | 0.1 | 0.1 | 0.1 | 0.1~0.3 | - | |
| Fe | 0.5 | 0.7 | 0.6 | 0.5 | 0.6 | 0.7 | |
| Ni | 0.5 | 0.3 | 0.3 | 0.5 | 0.5 | 0.1 | |
| Al | - | - | - | - | - | Balance | |
| Other | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | |
| Performance Data | Sliding | ★★★★★ | ★★★★★ | ★★★★ | ★★★★★ | ★★★★ | ★★★★ |
| Abrasion Resistance | ★★★★★ | ★★★ | ★★★★ | ★★★★ | ★★★★ | ★★★★ | |
| Hardness | ★★★★★ | ★★ | ★★★★ | ★★★ | ★★★★ | ★★ | |
| Anti-bite Shaft | ★★★★ | ★★★★★ | ★★★ | ★★★★ | ★★★ | ★★★★ | |
| Corrosion-resistant | ★★★★★ | ★★ | ★★★★ | ★★★★ | ★★★★ | ★★★ | |
| High loading | ★★★★★ | ★★ | ★★★★ | ★★★★ | ★★★★ | ★★★ | |
| Anti-fatigue | ★★★★★ | ★★★ | ★★★★ | ★★★★ | ★★★★ | ★★★ | |
| Environmental protection | x | x | x | ★★ | ★★ | ★ | |
|
|
